STS-F tömszelence
STS-F tömszelence
Termékleírás
metric thread
| Part no. | Size
Metr. |
Cable thickness from / to mm |
Cable width from / to mm |
Thread length mm |
Spanner size mm |
Unit |
|---|---|---|---|---|---|---|
| 94484 | M20 x 1,5 | 1,0 – 5,0 | 3,0 – 16,0 | 6,0 | 24 / 22 | 50 |
| 94485 | M25 x 1,5 | 3,0 – 8,0 | 9,0 – 21,0 | 7,0 | 30 / 28 | 50 |
| 94486 | M32 x 1,5 | 4,0 – 11,5 | 14,0 – 30,0 | 8,0 | 39 / 37 | 25 |
| 94487 | M40 x 1,5 | 4,0 – 11,5 | 24,0 – 40,0 | 8,0 | 50 / 47 | 10 |
| 94488 | M50 x 1,5 | 5,0 – 12,0 | 29,0 – 45,0 | 9,0 | 57 / 54 | 5 |
| 94489 | M63 x 1,5 | 5,0 – 12,0 | 34,0 – 50,0 | 10,0 | 66 / 60 | 5 |
PG thread
| Part no. | Size
PG |
Cable thickness from / to mm |
Cable width from / to mm |
Thread length mm |
Spanner size mm |
Unit |
|---|---|---|---|---|---|---|
| 90100 | 16 | 1,0 – 5,0 | 3,0 – 16,0 | 6,5 | 24 / 22 | 50 |
| 90101 | 21 | 3,0 – 8,0 | 9,0 – 21,0 | 7,0 | 30 / 28 | 50 |
| 90102 | 29 | 4,0 – 11,5 | 14,0 – 30,0 | 8,0 | 40 / 37 | 25 |
| 90103 | 36 | 4,0 – 11,5 | 24,0 – 40,0 | 9,0 | 50 / 47 | 20 |
| 90104 | 42 | 5,0 – 12,0 | 29,0 – 45,0 | 10,0 | 57 / 54 | 10 |
| 90105 | 48 | 5,0 – 12,0 | 34,0 – 50,0 | 10,0 | 64 / 60 | 5 |
